1. Precautions for opening top box:

(1) For ultra-wide and ultra-high goods, the general limit of width and height is within 4 meters. Once it is over 4 meters, select grocery transport

(2) When asking for a quotation, attention should be paid to whether the size of the goods is within or outside the specifications

(3) The open top does not mean that the transportation is really "open", the waterproof and protection requirements of the open top box goods are the same as those of ordinary containers, so the top must be covered with waterproof devices after loading.

(4) During the open-top cabinet transportation operation, cover the tarpaulin, master the highway width and high standard, arrange the trailer according to the specific situation of the goods, and calculate the trailer cost according to the situation of the goods.

(5) Open-top cabinet transport bundling, first of all, to understand the specific situation of the goods, shape and weight, to decide which open-top cabinet size needs to be used, the key is the balance of the center of gravity; The main materials are steel wire, joint, lashing tape, small wooden pad and so on. The binding points must be well connected to the whole, the force is firm, and the distance between the binding points should be short; If there is no binding point, bind the goods as a whole according to the size of the goods. After the bundling is completed, it is best to take photos, and keep the photos of the open top cabinet after the bundling for backup. If the professional guide is not present, it is also convenient to transmit this picture of the open top cabinet for bundling guidance to see whether the bundling is correct. At the time of inquiry, it is necessary to ask who is responsible for tying and who bears the cost.

There is no top on the cabinet structure, the stability of the open-top cabinet is worse than that of the ordinary cabinet, so the bearing capacity is smaller than that of the ordinary cabinet. The maximum bearing capacity of the open-top 20 is 27.6t, and the maximum bearing capacity of the open-top 40 is 26.2t.

2. Precautions for flat box:

(1) Bundle/support/fix the flat cabinet and trailer during transportation, pay attention to balanced placement, and keep the center of gravity stable. According to the needs of the goods themselves, waterproof and moisture-proof measures must be taken, and the packaging strength is better to avoid the rupture of the packaging during the transportation of the goods.

(2) The main body of the goods is fixed on the cabinet with steel cables.

(3) The front and back of the goods must be effectively reinforced, in addition to the reinforcement of sufficient steel wire rope, should also be installed to prevent the goods from moving forward and backward.

(4) Bulk goods must be properly packed, preferably unpacked or empty boxes. There must be a pad between the steel cables and wooden cases for bundling flat cabinets.

(6) Provide shipment drawing/plan of the goods before shipment. Whether the goods can be shipped depends not only on whether the flat cabinet bunching and reinforcement, trailer arrangement, etc., but also on whether the port equipment can bear this batch of goods, considering the actual operation and route arrangement of each port.

The flat cabinet is also due to the load-bearing reasons of the cabinet itself and the lifting capacity of the dock lifting equipment, the maximum load-bearing capacity of a single cabinet is 31 tons of 20 feet board, 40 feet board 40 tons, and the width and height are basically limited to 4M.

2.20 Size Flat board cabinet:

The floor height is 2.2 meters, the thicker the floor, the larger the space, the smaller the load, the container load of 27.7 tons, nuclear load of 31 tons.

40 size flat board cabinet:

Height 1.95 meters, load 30 tons, approved load 40 tons.

General cabinet type and special container size

3. What information should OOG ask the customer to provide during the inquiry?

The quotation of OOG special cabinets is very different from that of ordinary cabinets, and the price should be determined according to the specific size, volume and weight of the goods.

When inquiring, please remember to provide the special container size, weight and delivery date of the goods after packaging. If the goods are too large and uneven in weight, please also provide pictures, so that the shipping company can judge whether the goods can be transported.
